A bundle that includes both the Garage Tinkering automotive PCB v1.1 and a high brightness anti-glare screen.
PCB includes:
ESP32-S3-WROOM-1U-N8R8
Daisy-chain CANBus and 5V throughput
i2c connector
GPIO connectors
Vertical UART USB
40-pin RGB LCD connection
External antenna included
Exclusive screen features:
2.1” RGB LCD screen
Ultra high brightness (1000nits)
Anti-glare hardened glass coating
Scratch and dust resistant
A 3D printable enclosure is currently in progress and will be complete by the time these products ships. These will be provided for free at a later date if you want to get it printed. Otherwise will we offer printing and injection molded pieces shortly.
